Products-589 Record(s)
Mfr Part # | Price ($) | Quantity Available | Series | Package | Product Status | Input Impedance | Measurement Error | Voltage - I/O High | Voltage - I/O Low | Current - Supply | Voltage - Supply | Meter Type | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| $5.75 | 648 | - | Tray | Active | 113kOhm, 256kOhm, 7.8MOhm | 0.25% | 2.4V, 2.5V | 0.8V, 0.4V | 9.3mA | 2.97 V ~ 3.63 V | Single Phase | ||
| $2.11 | 7628 | - | Bulk | Active | 400kOhm | 0.1% | 2.4V, 4.5V | 0.8V, 0.5V | 2mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $0.96 | 275 | - | Tube | Active | 390kOhm | 0.1% | 2.4V, 4V, 4.5V | 0.5V, 0.8V | 3mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $6.17 | 1902 | - | Tape & Reel (TR) | Active | 370kOhm | 0.1% | 2.4V | 0.8V | 7mA | 4.75 V ~ 5.25 V | 3 Phase | ||
| $12.04 | 155 | - | Tube | Active | - | 0.4% | - | - | 900µA | 2.7 V ~ 100 V | Single Phase | ||
| $30.14 | 914 | - | Tape & Reel (TR) | Active | 113kOhm, 256kOhm, 7.8MOhm | 0.25% | 2.4V, 2.5V | 0.8V, 0.4V | 9.3mA | 2.97 V ~ 3.63 V | Single Phase | ||
| $6.17 | 2242 | - | Tape & Reel (TR) | Active | 400kOhm | 0.2% | 2V, 2.4V | 0.4V, 0.8V | 20mA | 2.8 V ~ 3.7 V | 3 Phase | ||
| $15.74 | 2401 | - | Tape & Reel (TR) | Active | - | 1.2% | - | - | 6mA | 4.5 V ~ 15 V | Single Phase | ||
| $5.48 | 140 | - | Tube | Active | 390kOhm | 0.1% | 2.4V | 0.8V | 3mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $20.55 | 4000 | - | Tray | Active | 400kOhm | 0.2% | 2V, 2.4V | 0.4V, 0.8V | 20mA | 2.8 V ~ 3.7 V | 3 Phase | ||
| $1.55 | 6000 | - | Bulk | Active | 390kOhm | 0.1% | 2.4V, 4.5V | 0.8V, 0.5V | 2mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $1.10 | 3010 | - | Bulk | Active | 390kOhm | 0.1% | 2.4V, 4.5V | 0.8V, 0.5V | 2mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $12.41 | 196 | - | Bulk | Active | - | - | 1.1V | 0.4V, 0.8V, 1.5V | 3.6mA | 2.95 V ~ 13 V | Single Phase | ||
| $1.78 | 350 | - | Bulk | Active | 390kOhm | 0.1% | 2.4V | 0.8V | 3mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $0.14 | 3320 | - | Tape & Reel (TR) | Active | 390kOhm | 0.1% | 2.4V, 4V | 0.4V, 0.8V, 1V | 3mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $7.08 | 4964 | - | Tape & Reel (TR) | Active | - | 0.4% | - | - | 900µA | 2.7 V ~ 100 V | Single Phase | ||
| $8.11 | 3134 | - | Tape & Reel (TR) | Active | - | 0.4% | - | - | 900µA | 2.7 V ~ 100 V | Single Phase | ||
| $12.42 | 2383 | - | Tape & Reel (TR) | Active | - | 1.2% | - | 0.4V | 6mA | 4.75 V ~ 15 V | Single Phase | ||
| $4.40 | 44255 | - | Bulk | Obsolete | 390kOhm | 0.1% | 2.4V | 0.8V | 3mA | 4.75 V ~ 5.25 V | Single Phase | ||
| Obsolete | 3350 | - | Bulk | Obsolete | 390kOhm | 0.1% | 2.4V | 0.8V | 3mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $0.96 | 2265 | - | Tube | Obsolete | 320kOhm | 0.1% | 2.4V | 0.8V | 5mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $2.77 | 2511 | - | Tube | Obsolete | 400kOhm | 0.1% | 2.4V | 0.8V | 4mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $1.21 | 13633 | - | Bulk | Obsolete | 390kOhm | 0.1% | 2.4V | 0.8V | 3mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $1.88 | 4237 | - | Tube | Obsolete | 320kOhm | 0.1% | 2.4V | 0.8V | 5mA | 4.75 V ~ 5.25 V | Single Phase | ||
| $3.43 | 3173 | - | Tray | Obsolete | 770kOhm | 0.1% | 1.3V, 2V, 2.4V | 0.4V, 0.8V | 4mA | 2.4 V ~ 3.7 V | Single Phase |
