Mfr Part # | Price ($) | Quantity Available | Series | Package | Product Status | Output Configuration | Applications | Interface | Load Type | Technology | Rds On (Typ) | Current - Output / Channel | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| $1.41 | 34476 | PowerTrench®, SyncFET™ | Bulk | Active | Half Bridge | Synchronous Buck Converters | PWM | Inductive | UMOS | 650mOhm LS, 650mOhm HS | 35A | ||
| $2.01 | 11945 | XS™ DrMOS | Bulk | Active | Half Bridge | Synchronous Buck Converters | PWM | Inductive | DrMOS | 1Ohm LS, 1Ohm HS | 43A | ||
| $0.55 | 9000 | - | Bulk | Obsolete | Half Bridge | Synchronous Buck Converters | PWM | Inductive | DrMOS | - | 25A | ||
| $14.39 | 379 | - | Tube | Obsolete | Half Bridge (3) | AC Motors | Logic | Inductive | IGBT | - | 20A | ||
| $10.96 | 2987 | XS™ DrMOS | Bulk | Active | Half Bridge | Synchronous Buck Converters | PWM | Inductive | DrMOS | 1Ohm LS, 1Ohm HS | 60A | ||
| Active | 4688 | - | Bulk | Active | Half Bridge (2) | DC-DC Converters | Logic | Inductive | Power MOSFET | - | - | ||
| $1.70 | 5980 | - | Bulk | Active | Half Bridge | Synchronous Buck Converters | Logic, PWM | Inductive, Capacitive, Resistive | DrMOS, Power MOSFET | 1Ohm LS, 1Ohm HS | 55A | ||
| $1.21 | 3972 | PowerTrench®, SyncFET™ | Bulk | Active | Half Bridge | Synchronous Buck Converters | PWM | Inductive | UMOS | 470mOhm LS, 680mOhm HS | 55A | ||
| $0.40 | 15200 | - | Bulk | Active | Half Bridge | Synchronous Buck Converters | Logic, PWM | Inductive, Capacitive, Resistive | DrMOS, Power MOSFET | 1Ohm LS, 1Ohm HS | 50A | ||
| $6.85 | 2350 | - | Bulk | Active | - | - | - | - | - | 750mOhm | - | ||
| $5.33 | 4917 | Automotive, AEC-Q100 | Tape & Reel (TR) | Active | Half Bridge | DC Motors, Solenoids | Analog, PWM, Serial, SPI | Inductive, Capacitive, Resistive | Power MOSFET | 2.8Ohm LS (Max), 13.9Ohm HS (Max) | 2.1A | ||
| $2.74 | 2209 | - | Tape & Reel (TR) | Active | Half Bridge (2) | General Purpose | Logic, PWM, SPI | Inductive, Capacitive, Resistive | Power MOSFET | 1.5Ohm LS, 1.5Ohm HS | 6A | ||
| $4.35 | 240 | - | Bulk | Active | Half Bridge (3) | AC Motors | Logic | Inductive | MOSFET (Metal Oxide) | 340mOhm LS, 340mOhm HS | 4.6A | ||
| Active | 2419 | µIPM™ | Bulk | Active | Half Bridge (3) | AC Motors | Logic | Inductive | UMOS | 4.8Ohm | 1A | ||
| Active | 3071 | µIPM™-DIP | Bulk | Active | Half Bridge (3) | AC Motors | Logic | Inductive | UMOS | 1.3Ohm | 2.4A | ||
| $3.89 | 1860 | µIPM™-DIP | Bulk | Active | Half Bridge (3) | AC Motors | Logic | Inductive | UMOS | 5Ohm | 1.2A | ||
 | $2.06 | 8072 | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | |
| $4.80 | 2000 | µIPM™ | Tape & Reel (TR) | Active | Half Bridge | AC Motors | Logic | Inductive | UMOS | 130mOhm | 20A | ||
| $3.67 | 2160 | - | Bulk | Active | Half Bridge (3) | AC Motors | Logic, PWM | Inductive, Capacitive, Resistive | NMOS | 340mOhm | 4.6A | ||
| $11.19 | 230 | µIPM™-DIP | Tube | Discontinued at | Half Bridge (3) | AC Motors | Logic | Inductive | UMOS | 1Ohm | 2.6A | ||
| $0.41 | 2500 | - | Tape & Reel (TR) | Active | Half Bridge (2) | Battery Powered | Logic | - | Power MOSFET | - | 600mA | ||
| $12.33 | 1943 | µIPM™ | Tape & Reel (TR) | Active | Half Bridge | AC Motors, DC Motors, DC-DC Converters, General Purpose | Logic | Inductive, Capacitive | Power MOSFET | 16mOhm | 30A | ||
| $1.38 | 174 | * | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - | ||
| $3.43 | 1000 | Automotive, AEC-Q100 | Tape & Reel (TR) | Active | Half Bridge (2) | DC Motors, General Purpose | PWM, SPI | Inductive | Power MOSFET | 100mOhm LS, 100mOhm HS | 6A | ||
| $1.51 | 10000 | - | Tape & Reel (TR) | Active | Half Bridge | DC Motors, General Purpose | PWM | Inductive | Power MOSFET | 4.7mOhm LS, 5.3mOhm HS | 55A |
