Products-721 Record(s)

Mfr Part #	Price ($)	Quantity Available	Series	Product Status	Type	Configuration	Current	Voltage	Voltage - Isolation	Mounting Type	Package / Case	Package
FSBB30CH60CM SMART POWER MODULE Fairchild Semiconductor	$16.44	3340	*	Active	-	-	-	-	-	-	-	Bulk
FSBS10CH60T SMART POWER MODULE 27PIN SPM27-B onsemi	$3.43	2493	Motion-SPM®	Active	IGBT	3 Phase	10 A	600 V	2500Vrms	Through Hole	27-PowerDIP Module (1.205", 30.60mm)	Bulk
FSB67508 AC MOTOR CONTROLLER, 95A onsemi	$2.91	166	-	Obsolete	-	-	-	-	-	Through Hole	10-PowerSIP Module, Formed Leads	Tube
FSB50325 AC MOTOR CONTROLLER, 3A, HYBRID onsemi	$3.87	240	SPM®	Obsolete	MOSFET	3 Phase	1.5 A	250 V	1500Vrms	Through Hole	23-PowerDIP Module (0.551", 14.00mm)	Tube
FSB50260SF AC MOTOR CONTROLLER, 5.2A onsemi	$4.48	540	Motion SPM® 5 SuperFET®	Obsolete	MOSFET	3 Phase	1.7 A	600 V	1500Vrms	Through Hole	23-PowerDIP Module (0.551", 14.00mm)	Tube
FNA51560T3 AC MOTOR CONTROLLER, 30A onsemi	$9.32	10109	Motion SPM® 55	Active	IGBT	3 Phase	15 A	600 V	1500Vrms	Through Hole	20-PowerDIP Module (1.220", 31.00mm)	Tube
FSB50550UTD AC MOTOR CONTROLLER, 5A, PDIP23 onsemi	$9.80	49276	Motion SPM® 5	Active	MOSFET	3 Phase Inverter	2 A	500 V	1500Vrms	Through Hole	23-PowerDIP Module (0.748", 19.00mm)	Bulk
FSBF3CH60B AC MOTOR CONTROLLER, 6A onsemi	$9.85	108	Motion-SPM®	Obsolete	IGBT	3 Phase	3 A	600 V	2500Vrms	Through Hole	27-PowerDIP Module (1.205", 30.60mm)	Tube
FSBF5CH60B AC MOTOR CONTROLLER, 10A onsemi	$6.85	1200	Motion SPM® 3	Active	IGBT	3 Phase	5 A	600 V	2500Vrms	Through Hole	27-PowerDIP Module (1.205", 30.60mm)	Bulk
FSBS15CH60L SMART POWER MODULE onsemi	$14.28	180	SPM®	Active	IGBT	3 Phase	15 A	600 V	2500Vrms	Through Hole	27-PowerDIP Module (1.205", 30.60mm)	Bulk
FSAM10SH60 AC MOTOR CONTROLLER onsemi	$10.91	195	SPM®	Obsolete	IGBT	3 Phase	10 A	600 V	2500Vrms	Through Hole	32-PowerDIP Module (1.370", 34.80mm)	Tube
FSBB20CH60SL SMART POWER MODULE Fairchild Semiconductor	$6.85	600	Motion-SPM®	Active	IGBT	3 Phase	20 A	600 V	2500Vrms	Through Hole	27-PowerDIP Module (1.205", 30.60mm)	Bulk
FSAM15SM60A AC MOTOR CONTROLLER, 30A, HYBRID onsemi	$2.06	150	Motion SPM® 2	Obsolete	IGBT	3 Phase	15 A	600 V	2500Vrms	Through Hole	32-PowerDIP Module (1.370", 34.80mm)	Tube
FSBB30CH60F AC MOTOR CONTROLLER, 60A, HYBRID onsemi	$9.32	503	Motion SPM® 3	Active	IGBT	3 Phase Inverter	30 A	600 V	2500Vrms	Through Hole	27-PowerDIP Module (1.205", 30.60mm)	Bulk
FSBF15CH60CT AC MOTOR CONTROLLER, 30A, HYBRID onsemi	$21.68	156	Motion-SPM®	Obsolete	-	-	-	-	-	Through Hole	27-PowerDIP Module (1.205", 30.60mm)	Tube
FSBB30CH60B AC MOTOR CONTROLLER, 60A, HYBRID onsemi	$26.03	119	Motion-SPM®	Obsolete	IGBT	3 Phase	30 A	600 V	2500Vrms	Through Hole	27-PowerDIP Module (1.205", 30.60mm)	Tube
FSB32560 AC MOTOR CONTROLLER, 25A, HYBRID onsemi	$30.24	4699	Motion SPM® 3	Active	IGBT	3 Phase Inverter	25 A	600 V	2500Vrms	Through Hole	27-PowerDIP Module (1.205", 30.60mm)	Bulk
FSBB20CH60L AC MOTOR CONTROLLER, 40A onsemi	$36.28	157	SPM®	Obsolete	IGBT	3 Phase	20 A	600 V	2500Vrms	Through Hole	27-PowerDIP Module (1.205", 30.60mm)	Tube
FSAM20SM60A AC MOTOR CONTROLLER, 40A, HYBRID onsemi	$2.74	13302	Motion SPM® 2	Active	IGBT	3 Phase	20 A	600 V	2500Vrms	Through Hole	32-PowerDIP Module (1.370", 34.80mm)	Bulk
FSB50660SFS AC MOTOR CONTROLLER, 8.1A onsemi	Active	4594	Motion SPM® 5 SuperFET®	Active	MOSFET	3 Phase	3.1 A	600 V	1500Vrms	Surface Mount	23-PowerSMD Module, Gull Wing	Bulk
FSB50250A AC MOTOR CONTROLLER, 3.1A onsemi	$3.36	123	Motion SPM® 5	Active	IGBT	3 Phase	1.2 A	500 V	1500Vrms	Through Hole	23-PowerDIP Module (0.573", 14.56mm)	Bulk
FSB50825AB AC MOTOR CONTROLLER, 9A, HYBRID onsemi	$4.11	172	Motion-SPM®	Active	MOSFET	3 Phase	3.6 A	250 V	1500Vrms	Through Hole	23-PowerDIP Module (0.644", 16.35mm)	Bulk
FSB50250AB AC MOTOR CONTROLLER, 3.1A, HYBRI onsemi	$3.36	180	SPM®	Active	MOSFET	3 Phase	1.2 A	500 V	1500Vrms	Through Hole	23-PowerDIP Module (0.644", 16.35mm)	Bulk
FF450R08A03P2XKSA1 IGBT MODULE Infineon Technologies	$233.06	206	-	Active	IGBT	Half Bridge	450 A	750 V	2500Vrms	Chassis Mount	Module	Tube
IKCM15L60GDXKMA1 IFPS MODULE 600V 20A 24PWRDIP Infineon Technologies	$5.21	7000	CIPOS™	Active	IGBT	3 Phase	20 A	600 V	2000Vrms	Through Hole	24-PowerDIP Module (1.028", 26.10mm)	Tube
