Products-623 Record(s)

Customize Columns

Mfr Part #	Price ($)	Quantity Available	Series	Package	Product Status	Transistor Type	Current - Collector (Ic) (Max)	Voltage - Collector Emitter Breakdown (Max)	Resistor - Base (R1)	Resistor - Emitter Base (R2)	DC Current Gain (hFE) (Min) @ Ic, Vce	Vce Saturation (Max) @ Ib, Ic
BCR08PNH6433XTMA1 PRE-BIASED BIPOLAR TRANSISTOR (B Cypress Semiconductor Corp	$0.08	10000	-	Tape & Reel (TR)	Obsolete	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	2.2kOhms	47kOhms	70 @ 5mA, 5V	300mV @ 500µA, 10mA
MUN5311DW1T1G TRANS PREBIAS 1NPN 1PNP 50V SC88 onsemi	$0.02	240000	-	Tape & Reel (TR)	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	10kOhms	10kOhms	35 @ 5mA, 10V	250mV @ 300µA, 10mA
MUN5135DW1T1G TRANS PREBIAS 2PNP 50V SC88 onsemi	$0.06	53969	-	Tape & Reel (TR)	Active	2 PNP - Pre-Biased (Dual)	100mA	50V	2.2kOhms	47kOhms	80 @ 5mA, 10V	250mV @ 300µA, 10mA
MUN5214DW1T1G TRANS 2NPN PREBIAS 0.25W SOT363 onsemi	$0.21	315000	-	Tape & Reel (TR)	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	10kOhms	47kOhms	80 @ 5mA, 10V	250mV @ 300µA, 10mA
MUN5211DW1T1G TRANS PREBIAS 2NPN 50V SC88 onsemi	$0.03	30000	-	Tape & Reel (TR)	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	10kOhms	10kOhms	35 @ 5mA, 10V	250mV @ 300µA, 10mA
MUN5312DW1T1G TRANS PREBIAS NPN/PNP SOT363 onsemi	$0.02	3000	-	Tape & Reel (TR)	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	22kOhms	22kOhms	60 @ 5mA, 10V	250mV @ 300µA, 10mA
SMUN5211DW1T1G TRANS PREBIAS 2NPN 50V SC88 onsemi	$0.04	60000	Automotive, AEC-Q101	Tape & Reel (TR)	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	10kOhms	10kOhms	35 @ 5mA, 10V	250mV @ 300µA, 10mA
MUN5213DW1T1G TRANS PREBIAS 2NPN 50V SC88 onsemi	$0.03	25	-	Tape & Reel (TR)	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	47kOhms	47kOhms	80 @ 5mA, 10V	250mV @ 300µA, 10mA
MUN5311DW1T2G TRANS PREBIAS 1NPN 1PNP 50V SC88 onsemi	$0.07	8794	-	Tape & Reel (TR)	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	10kOhms	10kOhms	35 @ 5mA, 10V	250mV @ 300µA, 10mA
MUN5114DW1T1G TRANS PREBIAS 2PNP 50V SC88 onsemi	$0.07	23040	-	Tape & Reel (TR)	Active	2 PNP - Pre-Biased (Dual)	100mA	50V	10kOhms	47kOhms	80 @ 5mA, 10V	250mV @ 300µA, 10mA
MUN5330DW1T1G TRANS PREBIAS 1NPN 1PNP 50V SC88 onsemi	$0.02	102000	-	Tape & Reel (TR)	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	1kOhms	1kOhms	3 @ 5mA, 10V	250mV @ 5mA, 10mA
MUN5215DW1T1G TRANS 2NPN PREBIAS 0.25W SOT363 onsemi	$0.69	8870	-	Tape & Reel (TR)	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	10kOhms	-	160 @ 5mA, 10V	250mV @ 1mA, 10mA
MUN5334DW1T1G TRANS PREBIAS NPN/PNP SOT363 onsemi	$0.41	8737	-	Tape & Reel (TR)	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	22kOhms	47kOhms	80 @ 5mA, 10V	250mV @ 1mA, 10mA
NSBC123JPDXV6T1G TRANS PREBIAS NPN/PNP 50V SOT563 onsemi	$0.07	7470	-	Tape & Reel (TR)	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	2.2kOhms	47kOhms	80 @ 5mA, 10V	250mV @ 300µA, 10mA
IMD10AMT1G TRANS NPN/PNP PREBIAS SC74R onsemi	$0.14	3000	-	Tape & Reel (TR)	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	500mA	50V	13kOhms, 130Ohms	10kOhms	100 @ 1mA, 5V / 68 @ 100mA, 5V	300mV @ 1mA, 10mA
SMUN5214DW1T1G TRANS 2NPN PREBIAS 0.187W SOT363 onsemi	$1.66	95000	-	Tape & Reel (TR)	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	10kOhms	47kOhms	80 @ 5mA, 10V	250mV @ 300µA, 10mA
NSTB60BDW1T1G TRANS PREBIAS 1NPN 1PNP 50V SC88 onsemi	$0.31	5446	-	Tape & Reel (TR)	Active	1 NPN Pre-Biased, 1 PNP	150mA	50V	22kOhms	47kOhms	80 @ 5mA, 10V / 120 @ 5mA, 10V	250mV @ 5mA, 10mA / 500mV @ 5mA, 50mA
MUN5316DW1T1G TRANS PREBIAS 1NPN 1PNP 50V SC88 onsemi	$0.02	7575	-	Tape & Reel (TR)	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	4.7kOhms	-	160 @ 5mA, 10V	250mV @ 1mA, 10mA
NSBC114EDXV6 TRANS 2NPN PREBIAS 0.5W SOT563 onsemi	$0.04	12000	*	Bulk	Active	-	-	-	-	-	-	-
MUN5335DW1T2G TRANS NPN/PNP PREBIAS 0.25W SC88 onsemi	$0.08	33000	-	Tape & Reel (TR)	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	2.2kOhms	47kOhms	80 @ 5mA, 10V	250mV @ 300µA, 10mA
MUN5231DW1T1G TRANS 2NPN PREBIAS 0.25W SOT363 onsemi	$0.02	9000	-	Tape & Reel (TR)	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	2.2kOhms	2.2kOhms	8 @ 5mA, 10V	250mV @ 5mA, 10mA
NSBC114EPDXVT1G SS SOT563 DUAL RSTR XSTR onsemi	$0.05	16000	*	Bulk	Active	-	-	-	-	-	-	-
SMUN5235DW1T3G TRANS 2NPN PREBIAS 0.187W SOT363 onsemi	$0.41	10000	-	Tape & Reel (TR)	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	2.2kOhms	47kOhms	80 @ 5mA, 10V	250mV @ 1mA, 10mA
NSVMUN5214DW1T3G TRANS NPN 50V DUAL BIPO SC88-6 onsemi	$0.41	10000	-	Tape & Reel (TR)	Active	2 NPN - Pre-Biased (Dual)	100mA	50V	10kOhms	47kOhms	80 @ 5mA, 10V	250mV @ 300µA, 10mA
NSBC124EPDXV6T1G TRANS PREBIAS NPN/PNP 50V SOT563 onsemi	$0.47	50	-	Tape & Reel (TR)	Active	1 NPN, 1 PNP - Pre-Biased (Dual)	100mA	50V	22kOhms	22kOhms	60 @ 5mA, 10V	250mV @ 300µA, 10mA
