Products-967 Record(s)

Customize Columns

Mfr Part #	Price ($)	Quantity Available	Series	Package	Product Status	Technology	Axis	Output Type	Sensing Range	Voltage - Supply	Current - Supply (Max)	Current - Output (Max)
A1308LLHLX-3-T SENSOR HALL EFFECT ANALOG SOT23W Allegro MicroSystems	$0.68	4472	-	Tape & Reel (TR)	Active	Hall Effect	Single	Analog Voltage	-	4.5V ~ 5.5V	11.5mA	2mA
A1366LKTTF-2-T LOW NOISE, HIGH-PRECISION LINEAR Allegro MicroSystems	$2.04	3832	-	Bulk	Active	Hall Effect	Single	Analog Voltage	-	4.5V ~ 5.5V	15mA	10mA
A1367LKTTF-5B-T PROGRAMMABLE LINEAR W/REVERSE BA Allegro MicroSystems	$2.21	8349	-	Bulk	Active	Hall Effect	Single	Analog Voltage	-	4.5V ~ 5.5V	16.25mA	10mA
MLX90333LGO-BCH-001-TU SENSOR HALL ANALOG/PWM 16TSSOP Melexis Technologies NV	Obsolete	0	Triaxis®	Tube	Obsolete	Hall Effect	X, Y, Z	Analog, PWM	20mT ~ 70mT (X,Y), 24mT ~ 140mT (Z)	4.5V ~ 5.5V	16mA	30mA
A1367LKTTN-2U-T SENSOR HALL EFFECT ANALOG 4SIP Allegro MicroSystems	$2.16	4808	Automotive, AEC-Q100	Tape & Reel (TR)	Active	Hall Effect	Single	Analog Voltage	-	4.5V ~ 5.5V	16.5mA	10mA
A1323ELHLT SENSOR HALL EFFECT ANALOG SOT23W Allegro MicroSystems	Obsolete	3280	-	Tape & Reel (TR)	Obsolete	Hall Effect	Single	Analog Voltage	-	4.5V ~ 5.5V	8mA	10mA
A1302KUA-T SENSOR HALL EFFECT ANALOG 3SIP Allegro MicroSystems	$1.65	29152	-	Bulk	Obsolete	Hall Effect	Single	Analog Voltage	-	4.5V ~ 6V	11mA	10mA
HG362A SENSOR HALL EFFECT ANALOG 4SIP Asahi Kasei Microdevices/AKM	$0.80	5178	-	Bulk	Active	Hall Effect	Single	Analog Voltage	-	12V	-	-
MLX90215EVA-AAA-106-RE SENSOR HALL Melexis Technologies NV	Obsolete	0	-	Bulk	Obsolete	Hall Effect	Single	Analog Voltage	-	4.5V ~ 5.5V	6.5mA	2mA
EQ732L SENSOR HALL EFFECT ANALOG 3SIP Asahi Kasei Microdevices/AKM	$1.02	9368	EQ	Tape & Reel (TR)	Active	Hall Effect	Single	Analog Voltage	-	3V ~ 5.5V	12mA	1.2mA
HW322-B-15-E SENSOR HALL EFFECT ANALOG 4SIP Asahi Kasei Microdevices/AKM	$1.79	595	-	Bulk	Active	Hall Effect	Single	Analog Voltage	-	-	20mA	-
MLX90290LUA-AAA-531-BU SENSOR HALL LINEAR ANALOG TO92 Melexis Technologies NV	$0.80	0	-	Bulk	Active	Hall Effect	Single	Analog Voltage	-	3.15V ~ 5.5V	8mA	20mA
MLX90290LUA-AAA-512-BU SENSOR HALL LINEAR ANALOG TO92 Melexis Technologies NV	$0.80	0	-	Bulk	Active	Hall Effect	Single	Analog Voltage	-	3.15V ~ 5.5V	8mA	20mA
MLX90295EVC-FAA-100-SP IC HALL SENSOR PREC PROG 4SIP Melexis Technologies NV	$3.43	0	-	Bag	Not For New Designs	Hall Effect	Single	Analog Voltage	156mT ~ 333mT	4.5V ~ 5.5V	9mA	40mA
TLE4998S8XUMA1 SENSOR HALL OPEN DRAIN TDSO-8 Infineon Technologies	$5.57	186	Automotive, AEC-Q100	Tape & Reel (TR)	Active	Hall Effect	Single	Open Drain	±50mT ~ ±200mT	4.5V ~ 5.5V	8mA	5mA
DRV5057A4QLPG SENSOR HALL EFFECT PWM Texas Instruments	$2.96	658	-	Bulk	Active	Hall Effect	Single	PWM	±168mT	3V ~ 3.63V, 4.5V ~ 5.5V	10mA	20mA
HG0114 SENSOR LINEAR HALL EFFECT Asahi Kasei Microdevices/AKM	Obsolete	3417	*	Tape & Reel (TR)	Obsolete	-	-	-	-	-	-	-
A1321ELHLT SENSOR HALL EFFECT ANALOG SOT23W Allegro MicroSystems	$6.89	2760	-	Tape & Reel (TR)	Obsolete	Hall Effect	Single	Analog Voltage	-	4.5V ~ 5.5V	8mA	10mA
A1308LLHLX-05-T SENSOR HALL EFFECT ANALOG SOT23W Allegro MicroSystems	$0.55	4380	-	Tape & Reel (TR)	Active	Hall Effect	Single	Analog Voltage	-	4.5V ~ 5.5V	11.5mA	2mA
A1367LKTTF-2U-T PROGRAMMABLE LINEAR W/REVERSE BA Allegro MicroSystems	$2.21	3959	-	Bulk	Active	Hall Effect	Single	Analog Voltage	-	4.5V ~ 5.5V	16.25mA	10mA
TLE4998C4HALA1 SENSOR HALL PWM SSO3-10 Infineon Technologies	$7.51	2000	Automotive, AEC-Q100	Cut Tape (CT)	Active	Hall Effect	Single	PWM	±50mT, ±100mT, ±200mT	4.5V ~ 5.5V	8mA	5mA
MLX90393SLW-ABA-111-SP TRIAXIS MAGNETIC NODE - I2C_ADDR Melexis Technologies NV	$2.68	0	Automotive, AEC-Q100, Triaxis®	Bulk	Active	Hall Effect	X, Y, Z	I²C	-	2.2V ~ 3.6V	-	-
TLE4943CAAMA1 SPEED SENSORS Infineon Technologies	$3.07	4458	Automotive, AEC-Q100	Tape & Box (TB)	Not For New Designs	-	-	-	-	-	-	-
MLX90333KDC-BCH-100-TU SENSOR HALL EFFECT SPI 8SOIC Melexis Technologies NV	$3.50	0	Triaxis®	Tube	Active	Hall Effect	X, Y, Z	SPI	20mT ~ 70mT (X,Y), 24mT ~ 140mT (Z)	4.5V ~ 5.5V	16mA	30mA
A1301KLHLT-T SENSOR HALL EFFECT ANALOG SOT23W Allegro MicroSystems	$34.45	4299	-	Tape & Reel (TR)	Obsolete	Hall Effect	Single	Analog Voltage	-	4.5V ~ 6V	11mA	10mA
