Mfr Part #	Price ($)	Quantity Available	Series	Package	Product Status	Type	Filter Order	Technology	Number of Channels	Center / Cutoff Frequency	Attenuation Value	Resistance - Channel (Ohms)
IP4307CX4/LF,135 FILTER RC(PI) 75 OHM/36PF SMD NXP USA Inc.	Obsolete	2304	-	Tape & Reel (TR)	Obsolete	Low Pass	2nd	RC (Pi)	1	-	-	75
NUF2114MNT1G FILTER RC(PI) 9 OHM/60PF ESD SMD onsemi	$0.28	6000	-	Tape & Reel (TR)	Active	Low Pass	2nd	RC (Pi)	2	50MHz (Cutoff)	-30dB @ 900MHz ~ 3GHz	9
CSPEMI606G FILTER RC(PI) 100 OHM/15PF SMD onsemi	$0.06	900	-	Tape & Reel (TR)	Obsolete	Low Pass	2nd	RC (Pi)	6	120MHz (Cutoff)	30dB @ 1GHz ~ 3GHz	100
IP4251CZ12-6-TTL DATA LINE FILTER NXP USA Inc.	$0.14	109100	*	Bulk	Active	-	-	-	-	-	-	-
PEMI4QFN/HM,132 FILTER RC(PI) 45 OHM/16PF SMD NXP USA Inc.	$0.10	32000	PEMIxQFN	Bulk	Obsolete	Low Pass	2nd	RC (Pi)	4	-	15dB @ 800MHz ~ 3GHz	45
PCMF1HDMI2S,087 NEXPERIA PCMF1HDMI2S - COMMON-MO NXP Semiconductors	Active	4699	*	Bulk	Active	-	-	-	-	-	-	-
NUF6406MNT1G LOW CAPACITANCE 6 LINE EMI FILTE onsemi	$1.52	9000	*	Tape & Reel (TR)	Obsolete	-	-	-	-	-	-	-
CM1406-08DE FILTER RC(PI) 200 OHM/15PF SMD onsemi	$0.17	2455	-	Tape & Reel (TR)	Obsolete	Low Pass	2nd	RC (Pi)	8	105MHz (Cutoff)	30dB @ 800MHz ~ 3GHz	200
BGF106CE6328 SIM CARD INTERFACE FILTER Infineon Technologies	$0.12	562170	-	Bulk	Active	Low Pass	2nd	RC	3	290MHz (Cutoff)	16.9dB @ 800MHz ~ 4GHz	-
PEMI4QFN/HR,132 FILTER RC(PI) 45 OHM/21PF SMD NXP USA Inc.	$0.10	84000	PEMIxQFN	Bulk	Obsolete	Low Pass	2nd	RC (Pi)	4	-	18dB @ 800MHz ~ 3GHz	45
BGF108CE6328XTSA1 FILTER RC 70 OHM/17PF ESD SMD Infineon Technologies	Obsolete	5704	-	Tape & Reel (TR)	Obsolete	Low Pass	2nd	RC	7	-	45dB @ 800MHz ~ 2GHz	70
PEMI8QFN/RE,132 FILTER RC(PI) 100 OHM/8.5PF SMD NXP USA Inc.	$0.18	2024	PEMIxQFN	Tape & Reel (TR)	Obsolete	Low Pass	2nd	RC (Pi)	8	-	13dB @ 800MHz ~ 3GHz	100
IP3338CX24/LF/P135 DATA LINE FILTER NXP USA Inc.	$0.46	4500	*	Bulk	Active	-	-	-	-	-	-	-
NUF2221W1T2G FILTER RC(PI) 22 OHM/42PF SMD onsemi	$0.21	33000	-	Tape & Reel (TR)	Active	Low Pass	2nd	RC (Pi)	3	-	-	22
EMIF04-1K030F3 FILTER RC(PI) 1KOHM/24PF ESD SMD STMicroelectronics	$0.31	13078	IPAD™	Tape & Reel (TR)	Obsolete	Low Pass	2nd	RC (Pi)	4	-	-	1k
EMIF08-1502M16 FILTER RC(PI) 170 OHM/14PF SMD STMicroelectronics	$0.41	37640	EMIF	Tape & Reel (TR)	Obsolete	Low Pass	2nd	RC (Pi)	8	300MHz (Cutoff)	30dB @ 900MHz ~ 1.8GHz	170
PEMI6QFN/BYP,132 FILTER RC(PI) ESD SMD NXP USA Inc.	$0.16	16000	PEMIxQFN	Bulk	Obsolete	Low Pass	2nd	RC (Pi)	6	-	-	-
IP4035CX24/LF/P135 DATA LINE FILTER NXP USA Inc.	Active	2341	*	Bulk	Active	-	-	-	-	-	-	-
NUF8001MUT2G FILTER RC(PI) 100 OHM/12PF SMD onsemi	$0.14	22113	-	Tape & Reel (TR)	Active	Low Pass	2nd	RC (Pi)	8	160MHz (Cutoff)	-25dB @ 800MHz ~ 5GHz	100
CM1453-06CP FILTER LC(PI) 20NH/9.5PF ESD SMD onsemi	Obsolete	2329	Praetorian®	Tape & Reel (TR)	Obsolete	Low Pass	3rd	LC (Pi)	6	300MHz (Cutoff)	35dB @ 800MHz ~ 2.7GHz	-
IP4303CX4/P135 DATA LINE FILTER NXP USA Inc.	$0.05	359808	*	Bulk	Active	-	-	-	-	-	-	-
ST1284-01A8RL FILTER RC ESD SMD STMicroelectronics	$4.13	5487	ST1284	Tape & Reel (TR)	Obsolete	Low Pass	-	RC	17	-	-	-
EMIF02-SPK03F2 FILTER LC(PI) 250PF ESD SMD STMicroelectronics	$0.83	60000	EMIF	Tape & Reel (TR)	Active	Low Pass	3rd	LC (Pi)	2	-	-40dB @ 900MHz	0.07
PEMI2QFN/HM,115 FILTER RC(PI) 45 OHM/16PF SMD NXP USA Inc.	$0.07	3765	PEMIxQFN	Tape & Reel (TR)	Obsolete	Low Pass	2nd	RC (Pi)	2	-	15dB @ 800MHz ~ 3GHz	45
NUF9001FCT1G FILTER RC(PI) 100 OHM/45PF SMD onsemi	$0.67	3284	-	Tape & Reel (TR)	Obsolete	Low Pass	2nd	RC (Pi)	10	100MHz (Cutoff)	-35dB @ 800MHz ~ 3GHz	200
