Products-1203 Record(s)

Customize Columns

	Mfr Part #	Price ($)	Quantity Available	Series	Package	Product Status	Transistor Type	Current - Collector (Ic) (Max)	Voltage - Collector Emitter Breakdown (Max)	Resistor - Base (R1)	Resistor - Emitter Base (R2)	DC Current Gain (hFE) (Min) @ Ic, Vce	Vce Saturation (Max) @ Ib, Ic
	PDTC114ET215 NOW NEXPERIA PDTC114ET - SMALL S NXP USA Inc.	$0.02	235666	*	Bulk	Active	-	-	-	-	-	-	-
	PDTC144TM,315 NEXPERIA PDTC144 - NPN RESISTOR- NXP Semiconductors	$0.02	38936	*	Bulk	Active	-	-	-	-	-	-	-
	PDTA143XT,215 NEXPERIA PDTA143XT - SMALL SIGNA NXP Semiconductors	$0.02	547457	*	Bulk	Active	-	-	-	-	-	-	-
	PDTC114TT,215 NEXPERIA PDTC114TT - SMALL SIGNA NXP Semiconductors	$0.02	570724	*	Bulk	Active	-	-	-	-	-	-	-
	PDTC143TT,215 NEXPERIA PDTC143TT - SMALL SIGNA NXP Semiconductors	$0.02	422185	*	Bulk	Active	-	-	-	-	-	-	-
	PDTA114TMB,315 NEXPERIA PDTA114 - SMALL SIGNAL NXP Semiconductors	$0.02	668175	*	Bulk	Active	-	-	-	-	-	-	-
	PDTD113ZT,215 NEXPERIA PDTD113 - NPN 500 MA, NXP Semiconductors	$0.03	39000	*	Bulk	Active	-	-	-	-	-	-	-
	PDTC115EM,315 NOW NEXPERIA PDTC115EM - SMALL S NXP Semiconductors	Active	3699	-	Bulk	Active	NPN - Pre-Biased	20 mA	50 V	100 kOhms	100 kOhms	80 @ 5mA, 5V	150mV @ 250µA, 5mA
	PDTC124TS,126 TRANS PREBIAS NPN 500MW TO92-3 NXP USA Inc.	Obsolete	3897	-	Tape & Box (TB)	Obsolete	NPN - Pre-Biased	100 mA	50 V	22 kOhms	-	100 @ 1mA, 5V	150mV @ 500µA, 10mA
	PDTC143EU,115 TRANS PREBIAS NPN 200MW SOT323 NXP USA Inc.	Active	4500	*	Bulk	Active	-	-	-	-	-	-	-
	PDTC143EM,315 TRANS PREBIAS NPN 250MW SOT883 NXP USA Inc.	$0.02	132905	*	Bulk	Active	-	-	-	-	-	-	-
	PDTA124TM,315 TRANS PREBIAS PNP 250MW SOT883 NXP USA Inc.	$0.02	190000	*	Bulk	Active	-	-	-	-	-	-	-
	PDTA115TT,215 TRANS PNP W/RES 50V SOT-23 NXP USA Inc.	Active	4380	*	Bulk	Active	-	-	-	-	-	-	-
	PDTA114ET/DG/B2215 SMALL SIGNAL BIPOLAR TRANSISTOR NXP USA Inc.	$0.02	2156	*	Bulk	Active	-	-	-	-	-	-	-
	PDTA144EU/ZL115 SMALL SIGNAL BIPOLAR TRANSISTOR NXP USA Inc.	$0.04	4592	*	Bulk	Active	-	-	-	-	-	-	-
	PDTB143EU135 SMALL SIGNAL BIPOLAR TRANSISTOR NXP USA Inc.	Active	2724	*	Bulk	Active	-	-	-	-	-	-	-
	PDTC143EQA147 SMALL SIGNAL BIPOLAR TRANSISTOR NXP USA Inc.	Active	3965	*	Bulk	Active	-	-	-	-	-	-	-
	PDTD123YU115 0.5A, 50V, NPN, SOT323 NXP USA Inc.	Active	4442	*	Bulk	Active	-	-	-	-	-	-	-
	PDTC144WU,115 NOW NEXPERIA PDTC144WU - SMALL S NXP USA Inc.	$0.02	57000	-	Bulk	Active	NPN - Pre-Biased	100 mA	50 V	47 kOhms	22 kOhms	60 @ 5mA, 5V	150mV @ 500µA, 10mA
	PDTC143XMB315 NOW NEXPERIA PDTC143XMB - SMALL NXP USA Inc.	$0.02	159840	*	Bulk	Active	-	-	-	-	-	-	-
	PDTC143TMB,315 NOW NEXPERIA PDTC143TMB - SMALL NXP USA Inc.	$0.02	117900	-	Bulk	Active	NPN - Pre-Biased	100 mA	50 V	4.7 kOhms	-	200 @ 1mA, 5V	100mV @ 250µA, 5mA
	PDTA124XMB,315 NOW NEXPERIA PDTA124XMB - SMALL NXP USA Inc.	$0.02	154938	-	Bulk	Active	PNP - Pre-Biased	100 mA	50 V	22 kOhms	47 kOhms	80 @ 5mA, 5V	150mV @ 500µA, 10mA
	PDTC123JM,315 NOW NEXPERIA PDTC123JM - SMALL S NXP USA Inc.	$0.02	2024	-	Bulk	Active	NPN - Pre-Biased	100 mA	50 V	2.2 kOhms	47 kOhms	100 @ 10mA, 5V	100mV @ 250µA, 5mA
	PDTA144EU,115 NOW NEXPERIA PDTA144EU - SMALL S NXP USA Inc.	$0.02	44500	-	Bulk	Active	PNP - Pre-Biased	100 mA	50 V	47 kOhms	47 kOhms	80 @ 5mA, 5V	150mV @ 500µA, 10mA
	PDTA144TMB,315 NOW NEXPERIA PDTA144TMB - SMALL NXP USA Inc.	$0.02	169326	-	Bulk	Active	PNP - Pre-Biased	100 mA	50 V	47 kOhms	-	100 @ 1mA, 5V	150mV @ 500µA, 10mA
